CGLP ISO 150 is a mineral CLGP-Bettrackracköl. It is characterized by a special lubricating and sliding properties and high adhesion.
Circulating Oil CL 150 product data sheet
Circulating Oil CL 150 safety data sheet
CGLP ISO 150
Description
TIPP-OIL CGLP ISO 150 is a mineral CGLP slideway oil. It features a special lubricating and sliding properties and high adhesion. It is therefore particularly suitable for the lubrication of slide and Bed ways. CGLP ISO 150 is formulated with mineral base oils and contains additives and corrosion inhibitors to prevent rust, and stains on slide and Bed ways. It is largely resistant to aqueous Metal working fluids, such as drilling, cutting and grinding emulsions or solutions. The lubricant film is rinsed of these media is not to be washed or Fort.
Instructions for use
TIPP-OIL CGLP ISO 150 is for all types of Lubrication systems, such as pressure, circulation and the Central lubrication system for the dive - and pressure-running lubrication, as well as for the lubrication of Hand with oil can. It is also suitable for lubrication of bearings and gears.
specifications
- AFNOR E 60-203 L-G
- DIN 51502 (CGLP)
- DIN 51517-3
- DIN 51524-2
- GB 11118.1-94 L-HM
- SO 11158 HM
- ISO 6743-6 CKC
- SAE MS1007 type E
- SH/T 0361-98 L-G
Characteristics
- Very good Stick-Slip behavior
- Adhesion
- Good Demulsification Properties
- Good corrosion protection, no rust or stains
- Resistance to aqueous Metal working fluids
Technical specifications
| Properties | Data | unit | testing under |
| Kinematic Viscosity at 40°C | 150,0 | MM²/S | ISO 51562-2 |
| Kinematic Viscosity at 100°C | 15,0 | MM²/S | ISO 51562-2 |
| viscosity index | 100 | ISO 2909 | |
| Appearance | YELLOW | visually | |
| Density at 15°C | 887,0 | KG/M³ | DIN 51 757 |
| pour point | -18 | °C | ISO 3016 |
