Gear Extra 80W-90 GL-5

Gear Extra 80W-90 GL-5 ist ein Hypoidgetriebeöl auf Mineralölbasis mit speziellen Hochdruckzusätzen für Schaltgetriebe.

Gear Extra GL-5 80W-90 Produktdatenblatt
Gear Extra GL-5 80W-90 safety data sheet

Description

TIPP-OIL Gear Extra 80W-90 GL-5 Hypoid gear oil based on mineral oil with special high-pressure additives for gearbox. The optimal gear lubrication in all temperature range is guaranteed by the high pressure absorption capacity. Gear Extra 80W-90 GL-5 provides a stable Oil film for lubrication even under extreme conditions. It reduces friction and prevents wear and corrosion.

Instructions for use

TIPP-OIL Gear Extra 80W-90 GL-5 can be used both in Winter and in summer. Its universal use reduces the risk of Confusion and simplifies storage. Because of the balanced additive combination of properties, such as high pressure absorption ability, exceptionally good viscosity-temperature behaviour, a high oxidation stability, low pour points, good wear protection and Sludge.

Quality classification specification

  • API GL-5
  • NATO O-226
  • MIL-L-2105D
  • SAE J2360

Recommendation

  • MAN 342 type M1/M2
  • Scania STO 1-0
  • VOLVO 1273.10
  • ZF TE-ML 05A/07A/12E/16C/17B/19B/21A

Characteristics

  • Very good oxidation stability
  • Excellent Viscosity-Temperature Behavior
  • Protection against rust & corrosion, attack on non-ferrous metals
  • Good Age Resistance
  • Wear protection

Technical specifications

 Properties  Data  unit  testing under
 Kinematic Viscosity at 40°C  132,6  MM²/S  ISO 51562-2
 Kinematic Viscosity at 100°C   14,4  MM²/S  ISO 51562-2
 viscosity index  108  ISO 2909
 Appearance YELLOW  visually
 Density at 15°C  883,3  KG/M³  DIN 51 757
 pour point  -33  °C  ISO 3016



All data given are approximate values and are subject to normal production fluctuations. To the best of our knowledge, all information corresponds to the current state of knowledge and our development. We reserve the right to make changes. All references to DIN standards are only used to describe the goods and do not constitute a guarantee. In the event of problems, request technical advice.
