Hydraulic HVLP 46

Hydraulic HVLP 46 is a multi-range of hydraulic oil, which has been developed on the Basis of specially selected base oils.

Hydraulic HVLP 46 product data sheet
Hydraulic HVLP 46 safety data sheet

Category:

Description

TIPP-OIL Hydraulic HVLP 46 is on the basis of specially selected base oils developed multi-grade hydraulic oil. Hydraulic HVLP 46 offers effective additives with a high level of wear protection, even under extreme loads. Hydraulic HVLP 46 is characterized by good viscosity-temperature behaviour and reliable corrosion protection.

Instructions for use

TIPP-OIL Hydraulic HVLP 46 is mainly used in hydraulic systems with strongly fluctuating operating temperatures. Hydraulic HVLP 46 is ideally suited for heavy duty hydraulic systems of earthmoving machinery and agricultural machinery. It is favoured in the case of strongly fluctuating operating temperatures, and is allowed to contain in the case of hydraulic systems, the silver or silver - plated construction and operating elements are not used.

specifications

  • AFNOR NF E 48-603 HV
  • AFNOR NF E 48-690/1
  • CETOP RP 91H HV
  • DIN 51524-3
  • GB 111118.1 L-HV
  • ISO 11158HV
  • ISO 6743-4 HV
  • JCMAS HK VG32W
  • SAE MS1004

Recommendation

  • Bosch Rexroth RE 90220
  • Denison HF-0/HF-1/HF-2
  • Eaton/Sperry Vickers I-286-S
  • Eaton/Sperry Vickers M-2950-S
  • Fives Cincinnati P-68
  • GM LH-03-1-04, GM LS-2
  • Sauer-Danfoss 520L0463
  • US Steel 127 US Steel 136

Characteristics

  • Reliable protection against corrosion
  • Stable Viscosity Index
  • Very good oxidation stability
  • Very low pour point
  • Excellent wear protection
  • Good air and water separation, thereby preventing the formation of foam
  • Neutral to sealing materials

Technical specifications

 Properties  Data  unit  testing under
 Kinematic Viscosity at 40°C    46,6  MM²/S  ISO 51562-2
 Kinematic Viscosity at 100°C     8,0  MM²/S  ISO 51562-2
 viscosity index  145  ISO 2909
 Appearance  YELLOW  visually
 Density at 15°C  858,0  KG/M³  DIN 51 757
 pour point  -39  °C  ISO 3016



All data given are approximate values and are subject to normal production fluctuations. To the best of our knowledge, all information corresponds to the current state of knowledge and our development. We reserve the right to make changes. All references to DIN standards are only used to describe the goods and do not constitute a guarantee. In the event of problems, request technical advice.
